Customized Powered Fire Resistant Flexible Roller Conveyor
| Item Type | Roller Conveyor |
| Frame | aluminum/carbon steel/stainless steel/customerized |
| Assembly Line Width | 400mm / 500mm / 600mm / Customized |
| Assembly Line height | 720mm / 750mm / 800mm / Customized |
| Assembly Line Length | 1000mm / 2000mm / 3000mm / Customized |
| Drum Spacing | 100mm 120mm 150mm Customized |
| Voltage | 110V/220V/380V |
| Drum Gear | Single Gear Or Double Gear |
| Conveyor Speed | Customized,for exsample: 6meter/min |
| Drive Form | Motor Driven Transport |
1. Economic and practical, cost-effective;
2. Modular combination, easy to transport and maintain;
3. Reliable operation, low noise and safety;
4. Adjustable legs, wide application scope;
5. Surface electrostatic spray, beautiful appearance;
6. Adjustable convey speed;
7. Large load capability;
8. Lightweight design, fast installation;
| Product Name | Flexible roller conveyor |
| Roller | High-Quality Galvanized Roller |
| Height | 700~ 1000mm |
| Castor | Universal Castor |
| Feature | Extendable,Retractable,Bendable |
| Max Load Capacity | 40kgs/m |
| Motor Brand | SWE |
| Suitable For | Flat Bottom Cartons And Boxes |
| Roller Model | BCRC-500-400, CY25 transfer balls |
| Roller diameter | 50mm |
| Roller Length | 3500mm |
| Pitch | 50mm |
| Size | W500mmxL3500mmxH400mm |
| Power Type | Motor drive |
Flexible Roller Conveyor Product Features:
1) Roller is high quality galvanized roller.
2) Height can be adjusted, the adjusted height range is 700~ 1000mm.
3) Transport through altitude intercept between two legs.
4) The castor is used universal castor, the machine can be moved easily.
5) This item can extendable, retractable, and bendable, it can take curve flexibly even in zigzag narrow aisles.
6) As two-row roller have gaps, so only flat bottom items like cartons, boxes can be conveyed.
7) Max load capacity is 40kgs/m; the motor brand is SWE.
How to order a roller conveyor?
1. Tell us the conveying product's size and weight.
2. The length x width x height of the roller conveyor and the total loading weight.
3. The material and surface treatment: depending on the different working environments, decide the material and surface treatment (such as galvanized, stainless steel, chem-black, or rubber lagging).
4. The frame material: stainless steel, painting coated. Roller: stainless steel, steel galvanized, PVC.
